LC SC 20km 1550nm Optical Fiber Module , Fiber Channel Sfp Module

LC SC 20km 1550nm Optical Fiber Module , Fiber Channel Sfp Module
LC SC 20km 1550nm Optical Fiber Module , Fiber Channel Sfp Module LC SC 20km 1550nm Optical Fiber Module , Fiber Channel Sfp Module

Large Image :  LC SC 20km 1550nm Optical Fiber Module , Fiber Channel Sfp Module

Product Details:
Place of Origin: china
Brand Name: OEM
Certification: CE RoHS FCC
Model Number: OEM
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: $4~$5.00
Packaging Details: 10pcs in Plastic tray
Delivery Time: 1~3working days after payment
Payment Terms: T/T
Supply Ability: 100000pcs per month
Contact Now

LC SC 20km 1550nm Optical Fiber Module , Fiber Channel Sfp Module

Description
Type: Fiber Optic Transceivers No. Of Fiber: 1.
Use: FTTX Supply Voltage: 3.3V
Power: -8~-15dBm Data Rate: 155M
Wavelength: 1310nm/1550nm Transmission Distance: 20km
Interface: BIDI LC Fiber Type: SMF
DDMI: Yes Warranty: 1 Year
Selling Units: Single Item Single Package Size : 22X5X6 Cm
Single Gross Weight: 0.060 Kg Package Type: 10pcs/ Anti-static Box.
High Light:

LC SC Optical Fiber Module

,

1550nm Fiber Channel Sfp Module

,

20km Optical Fiber Module

LC/SC 155Mbps BIDI 20km SMF 1310/1550nm SFP Module Smf



Features

  • l Up to 20km transmission on SMF
  • l Up to 155Mbps
  • l 1310nm FP laser and PIN receiver
  • l Single LC/SC receptacle optical interface compliant
  • l 2-wire interface for integrated Digital Diagnostic monitoring
  • l Hot pluggable
  • l Very low EMI and excellent ESD protection
  • l +3.3V power supply
  • l Power consumption less than 1.0W
  • l Operating case temperature: 0~+70°C



Applications

  • l High-speed storage area networks
  • l Computer cluster cross-connect
  • l Custom high-speed data pipes



Compliance

  • l Compliant with IEEE802.3ah 100Base-BX
  • l Compliant with MSA SFF-8472
  • l Compliant with SFP MSA


Specification

Technical Parameters Descriptions
Model Number YXF-FE-B35L-20D
Fiber type SMF
Form Factor BIDI SFP
Data Rate 155Mbps
Wavelength 1310/1550nm
Distance 20KM
Sensitivity <-32.0dBm
Connector LC
Laser/Detector FP/PIN
DDM Yes
Output Power -8~-15dBm
Power Supply 3.3V
Temperature 0~70°C
Certificate CE,ROHS,FCC,ISO9001,SGS
Warranty 1Year
Selling Units Single
Applications

LC SC 20km 1550nm Optical Fiber Module , Fiber Channel Sfp Module 0
