SMF 155Mbps 60km 1550nm 1310nm BIDI LC Optical Fiber Module

Large Image : SMF 155Mbps 60km 1550nm 1310nm BIDI LC Optical Fiber Module

Product Details:

Place of Origin:	china
Brand Name:	OEM
Certification:	CE RoHS FCC
Model Number:	OEM

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	$7~9.00
Packaging Details:	10pcs in Plastic tray
Delivery Time:	1~3working days after payment
Payment Terms:	T/T
Supply Ability:	100000pcs per month

Contact Now

SMF 155Mbps 60km 1550nm 1310nm BIDI LC Optical Fiber Module

Description

Type:	Fiber Optic Transceivers	No. Of Fiber:	1.
Use:	FTTX	Supply Voltage:	3.3V
Power:	3~-5dBm	Data Rate:	155M
Wavelength:	1550nm/1310nmn	Transmission Distance:	60km
Interface:	BIDI LC	Fiber Type:	SMF
DDMI:	Yes	Warranty:	1 Year
Selling Units:	Single Item	Single Package Size :	22X5X6 Cm
Single Gross Weight:	0.060 Kg	Package Type:	10pcs/ Anti-static Box.
Highlight:	155Mbps Optical Fiber Module , 1550nm Optical Fiber Module , 1310nm bidi sfp module

155M BIDI 60km 1550nm/1310nm LC/SC Connector

Features

l Up to 60km transmission on SMF
l Up to 155Mbps
l 1550nm DFB laser and PIN receiver
l Single LC/SC receptacle optical interface compliant
l 2-wire interface for integrated Digital Diagnostic monitoring
l Hot pluggable
l Very low EMI and excellent ESD protection
l +3.3V power supply
l Power consumption less than 1.0W
l Operating case temperature: 0~+70°C

Applications

l High-speed storage area networks
l Computer cluster cross-connect
l Custom high-speed data pipes

Compliance

l Compliant with IEEE802.3ah 100Base-BX
l Compliant with MSA SFF-8472
l Compliant with SFP MSA

Specification

Technical Parameters	Descriptions	Technical Parameters	Descriptions
Model Number	YXF-FE-B53L-60D	Interface	LC
Fiber type	SMF	Laser/Detector	DFB/PIN
Form Factor	BIDI SFP	DDM	Yes
Data Rate	155Mbps	Output Power	3~-5dBm
Wavelength	1550/1310nm	Power Supply	3.3V
Distance	60KM	Temperature	0~70°C
Sensitivity	<-34.0dBm	Certificate	CE,ROHS,FCC,ISO9001,SGS
Selling Units	Single	Warranty	1Year
