Product Details:
|
| Type: | Fiber Optic Transceivers | No. Of Fiber: | 1 |
|---|---|---|---|
| Use: | FTTX | Supply Voltage: | 3.3V |
| Data Rate: | 2.5G | Wavelength: | Tx1310/Rx1550nm, Tx1550/Rx1310nm |
| Transmission Distance: | 20km, 40km, 80km | Interface: | BIDI LC |
| Fiber Type: | SMF | DDMI: | Yes |
| Warranty: | 1 Year | Selling Units: | 1 Pair |
| Single Package Size : | 22X5X6 Cm | Single Gross Weight: | 0.060 Kg |
| Package Type: | 10pcs/ Anti-static Box. | ||
| High Light: | FTTX Sfp Bidirectional Transceiver,DDMI 2.5G SFP Module,WDM 2.5G SFP Module |
||
Features:
1. 2.5G- BIDI SFP 20km, 40KM, 80km etc LC connector
2. Dual data-rate of 2.5Gbps operation
3. 1550nm DFB laser and PIN photo detector
4. 1310nm DFB laser and PIN photo detector
5. BIDI LC/UPC type pluggable optical interface
6. Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
7. RoHS compliant and lead-free
8. Single +3.3V power supply
9. Support Digital Diagnostic Monitoring interface
10. Case operating temperature Commercial: 0°C to +70°C
Advantages:
1. The transceiver is a low power, high performance, cost effective module supporting data-rate up to 2.5Gbps Max 80km transmission distance.
2. The low jitter and high sensitivity are extinguished advantages with DFB LD and PIN receiver.
3. The transceiver incorporates TX_DIS control, TX-FAULT and RX_LOS monitor functions. The devices are Class I laser safety compliant.
Specifications:
| Technical Parameters | Descriptions | Technical Parameters | Descriptions |
| Model Number | YXF-2G | Interface | LC |
| Fiber type | SMF | Laser/Detector | DFB/PIN |
| Form Factor | BIDI SFP | DDM | Yes |
| Data Rate | 2.5Gbps | Certificate | CE,ROHS,FCC,ISO9001,SGS |
| Wavelength | 1310/1550nm, 1490/1550nm | Power Supply | 3.3V |
| Distance | 20KM, 40KM, 80KM | Temperature | 0~70°C |
